This manual hospital bed has three crank handles—the crank system is located at the foot end of the bed. This allows the mattress to raise and lower the upper body, legs and bed height. The bed height adjustment is most beneficial for ease of transfer and for caring for the user at the appropriate size. An ideal choice for those shopping on a budget but requiring a range of functionality, including height adjustment.
| Product Model: | JL633 |
| Overall Size | L2120×W970×H500-750mm |
| Sleeping platform size | L1950*W840mm |
| Loading capacity | hold 250kg working load |
| Functions | |
| 1)Back section | adjustable from 0°to 80°± 5°(by a mechanical crank) |
| 2)Knee section | adjustable from 0°to 40°± 5°(by a mechanical crank) |
| 3)Height adjustment | adjustable from 500-750mm (by a mechanical crank) |
| Bed structure | Electrophoresis and powder coating, no sharp edges, components security mounted |
| Basic Accessories | |
| 1)Head and footboard | One pair, detachable, ABS engineering plastic, smooth surface, with bumpers |
| 2)Side-rails | One pair, Aluminum alloy materials, six columns |
| 3)Castors | Four castors,dia. 125mm, double side, Easy manoeuvrability, brake and steer |
| 4)Cranks | Two cranks system, mechanical cranks, ABS or stainless steel handle |
| 5)Drainage bag hooks | Four hooks |
| 6)I.V pole | One pole, stainless steel, height adjustable |
| 7)I.V pole holders | Six holders, two on bed head, two on a bed end, two on bed middle |
| Package | Carton size: 205*100*37cm=0.76m³/bed G.W.: 82kgs |
For more information, contact us here.
Hand wash in cold water using neutral detergent. Do not tumble dry as it may degrade clinical elasticity.
